Functional requirements:

1. 1. Includes single-machine terminal running software;
2. 2. ★ using the robotic arm to achieve the book borrowing books to send books to the book, the book can be returned to the library on the device 24 hours, the device automatically returned to the book recycling bin;
3.  3. ★ use the ring-shaped rotating bookshelf to display books, try to expand the capacity, make full use of the space; when you manually add books to the equipment, you only need to open the control in the outside and you can put it on the shelves in order to solve the problem of manual installation of the first generation equipment. Inconvenient shortcomings such as shipping the book to the inside of the device.
4. 4. It can identify valid documents such as UHF library cards and provide borrowed books services;
5.  5. according to the library management process, self-help borrowing and returning books, renewal, appointment and other functions;
6.  6. through the console can query local books;
7.  7. Automatically extract bookshelf books according to the reader’s request and ship them to the borrowing and returning book;
8.  8. The left side of the equipment is designed with a logistics cabinet. The reserved books can be stored in the flow cabinet for the reader to extract according to the pick-up code. You can also cooperate with the logistics industry to make full use of equipment resources.
9.  9. in the dynamic management of books; with librarians fast book shelves and fast off the shelf function;
10.  10. Built-in certification system: support the self-service certificate through the second-generation ID card;
11.  11. built-in collection system: support deposits into advance payment and late payment self-deduction function;
12.  12. built-in printing system: can print the borrowed books borrowed by the reader;
13.  13. It can automatically detect the running status of the equipment and automatically realize remote monitoring and control of internal equipment.
14.  14. The left side of the device is an advertising screen with the function of reading the newspaper system and cooperating with the advertiser to play the advertisement.
15.  15. This machine is compatible with the bar code currently used by the library, but it needs a fixed position.
16.  16. The device has a reader-returning book recording function and an anti-theft monitoring system;

Parameters:

1. (1) Operating frequency: 860 ~ 960MHz (optional for RFID tags)
2. (2) Power supply requirements: AC 165V ~ 264V 50 ~ 60Hz;
3. (3) Power of the whole machine: standby ≤500W peak ≤1000W;
4. (4) The weight of the whole machine: 2500 kg;
5. (5) Relative humidity: ≤95%;
6. (6) Dimensions: 3.7 m × 1.5 m × 2.2 m (length x width x height);
7. (7) Protection level: IP42;
8. (8) Service life: 10 years;
9. (9) Operation noise: the running noise of the whole machine lm is ≤65dB;
10. (10) Bookshelf capacity: 450 bookshelf;
11. (11) Number of returned books: about 1,000 copies;
12. (12) Number of cards: 240;
13. (13) Number of deposits: 1000 sheets of 10-100 yuan bills;
14. (14) System identification: ≥99.99%;
15. (15) Book shelf/release time: ≤20 seconds/25 seconds;
16. (16) Operating temperature: 0 ° C ~ 50 ° C.
